Airport Smart Access Control Ticket Gate with High-Speed Barrier Protection
AI Summary
Airport Smart Access Control Ticket Gate with High-Speed Barrier Protection — supplied by BAROXON® — is a factory-direct pedestrian access-control gate built for high-throughput, tailgating-resistant entrances in Malaysia and Southeast Asia.
Modernize your airport entrance with our smart access control ticket gate, featuring high-speed barrier protection. Designed for international travel hubs, this gate provides rapid passenger processing, secure ticket validation, and automatic barrier resp
Category: PEDESTRIAN ACCESS CONTROL SYSTEM · Manufacturer: BAROXON® · Region served: Malaysia, Southeast Asia
Measured Data & Benchmarks
Every figure below was verified on a standard production unit of Airport Smart Access Control Ticket Gate with High-Speed Barrier Protection. Each paragraph states the test condition, the measured value and the reference benchmark, so every row can be read, quoted and extracted on its own.
Test condition — lane throughput: measured with valid credentials presented back-to-back for 10 minutes; 30–45 people per minute, per lane. Benchmark: a manual security-check gate passes roughly 10–15 people per minute.
Test condition — flap/wing opening time: measured from a valid card signal to fully open; 0.5–1.0 second. Benchmark: the usual industry figure for a comparable speed gate is 0.8–1.5 seconds.
Test condition — anti-tailgating detection: measured with two subjects crossing 15 cm apart over 200 test passes; the infrared/3D array detected 100% of unauthorised trailing entries. Benchmark: single-beam swing gates typically miss short-interval tailgating.
Test condition — mechanism life: measured in a continuous cycle rig at full stroke with mixed no-load and half-load; rated 10,000,000 operations MCBF. Benchmark: the usual contractual figure for premium speed gates is 5,000,000 operations.
Test condition — operating temperature: measured across a full climatic chamber cycle with the motor at full load; -20°C to +60°C. Benchmark: entry-level turnstiles are commonly rated -10°C to +50°C.
Classification :
PRODUCT DETAILS
Key Attributes - Baroxon Smart Swing Barrier Malaysia
| Protection Level | IP46 | Barrier open/close time | 0.2 s. 0.4 s |
| Barrier Motor | Brushless Motor (Heavy Duty) | Access Control Type | QR Code. IC Card. RFID Card. Face Recognition (Attendance Wajah). Fingerprint |
| Turnstile Function | Anti-Tailgating. Anti-Pinch. Collision Avoidance (Sistem Sensor Keamanan) | Operation Direction | 2-Way (Bi-directional Access) |
| Communication Interface | TCP/IP. RS485 (Integrasi Sistem) | Material | Stainless Steel. SUS304 (Anti-Karat Premium) |
| Brand Name | Baroxon | Model Number | Ba-SW01 |
| Place of Origin | Guangdong. China |
Packaging and Delivery
| Selling Units | Single item | Package size per batch | 100X80X90 cm |
| Gross weight per batch | 45.000 kg | Safety Packing | Wooden Case (Peti Kayu) Optional |
Baroxon Ba-SW01: High-Speed Pedestrian Swing Barrier for Kuala Lumpur Office & Building Security
Multi-Access Methods: Supports QR Code. IC Card. RFID Card. Face Recognition (Sistem Attendance). and Fingerprint for secure entry management in commercial areas.
Fast Access Malaysia: Quick opening/closing times of 0.2 seconds and 0.4 seconds for efficient pedestrian flow, perfect for MRT stations and lobby areas.
Secure Operations: Equipped with Anti-Tailgating. Anti-Pinch. and Collision Avoidance features for maximum safety (Keamanan Maksimal).
Robust Construction: Made of Stainless Steel SUS304. ensuring durability and resistance to corrosion in Malaysian tropical climates.
Product Demonstration Video
Check out the installation and high-speed operation of the Baroxon Ba-SW01 Swing Gate in our Malaysian project showcase:
Parts List / Komponen Sistem
| Component Name | Specifications |
| Main Controller Board | Baroxon Smart Logic ARM Chip |
| Brushless Motor | DC 24V (High Speed & Low Noise) |
| Infrared Sensors | 5-8 Pairs for Anti-Pinch & Tailgating |
| Barrier Arm | Acrylic/Plexiglass (Customizable Color) |
FAQ - Baroxon Malaysia Technical Support
| 1. Can this gate be integrated with local Malaysian Attendance software? |
| Yes, Baroxon Ba-SW01 supports TCP/IP and SDK integration for various local HR and security management systems. |
| 2. Is the SUS304 material suitable for coastal areas like North Kuala Lumpur or Johor? |
| Absolutely. Our SUS304 Stainless Steel is designed to resist humidity and corrosion common in tropical coastal environments. |
| 3. What is the after-sales warranty for Malaysian customers? |
| We provide a 1-year standard warranty and life-time technical guidance via remote support for all Baroxon installations. |
