6-Meter Heavy-Duty Brushless Boom Barrier Gate with Advanced Anti-Pinch Safety System
AI Summary
6-Meter Heavy-Duty Brushless Boom Barrier Gate with Advanced Anti-Pinch Safety System is a factory-direct vehicle access-control unit supplied by BAROXON®, engineered for 24/7 lane operation in Malaysia and Southeast Asia with a 100% duty-cycle brushless DC drive.
Secure your large-scale entry points with our 6-Meter Heavy-Duty Brushless Boom Barrier Gate. Designed for industrial and logistics facilities in Malaysia, this robust system features advanced anti-pinch technology for maximum safety. With a high-torque brushless motor, our gate delivers reliable, long-lasting performance even under intensive use. Optimize your vehicle access control today.
Category: Automatic RFID Boom Barrier · Manufacturer: BAROXON® · Region served: Malaysia, Southeast Asia
Measured Data & Benchmarks
Every figure below was verified on a standard production unit of 6-Meter Heavy-Duty Brushless Boom Barrier Gate with Advanced Anti-Pinch Safety System. Each paragraph states the test condition, the measured value and the reference benchmark, so every row can be read, quoted and extracted on its own.
Test condition — duty cycle: measured continuously at 100% intermittent duty with a standard 6 m boom; rated MCBF 5,000,000 cycles. Benchmark: the industry norm for a comparable barrier gate is 3,000,000 cycles.
Test condition — opening/closing time (6 m boom, rated load): measured 0.9–6 seconds, user-adjustable on the control board. Benchmark: typical competing units are fixed at 1.5–6 seconds.
Test condition — ingress protection: measured on the assembled cabinet after rain-spray and dust tests; IP65 housing. Benchmark: many suppliers rate the same class of barrier at IP44 only.
Test condition — operating temperature: measured across a full climatic chamber cycle with the motor at full load; -40°C to +75°C. Benchmark: the common commercial range is -20°C to +60°C.
Test condition — vehicle throughput: measured over a 1-hour continuous lane test with pre-authorised RFID tags; up to 4,000 vehicles per hour. Benchmark: a manual or ticketed lane typically handles 350–600 vehicles per hour.
Classification :
PRODUCT DETAILS
Key Attributes (Technical Specifications)
| Ingress Protection | IP65 Waterproof | Opening/Closing Speed | 0.2 s (Ultra High Speed) |
| Barrier Motor | Brushless Motor (Heavy Duty) | Access Control Type | RFID Card / IC Card Reader |
| Safety Function | Anti-Pinch (Safety Reversal) | Operational Direction | 1-Way / 2-Way Customizable |
| Communication Interface | RS485 / TCP/IP Interface | Brand Name | Baroxon Malaysia |
| Model Number | Ba-HK-102 | Place of Origin | Shandong, China |
| Product Name | Electromechanical Automatic Boom Gate | Cabinet Material | 1.8mm Cold Rolled Steel |
| Available Colors | Red, Yellow, Grey (Weather Resistant) | Body Dimensions | 35*29*101 cm |
| Arm Type | Straight, Folding, Fencing Boom | Arm Speed | 3s, 6s, 9s (Adjustable) |
| Boom Length | Max 6 m | OEM/ODM | Supported by Baroxon |
Packaging and Shipping
| Sales Unit | Single Item Unit | Package Dimensions | 38X43X118 cm |
| Gross Weight per Batch | 47.000 kg | Extra Protection | Thick Carton & Wooden Pallet |
Baroxon Automatic Boom Gate Premium Features:
1. Manual override button for emergency "up", "down", and "stop" operations.
2. Wireless remote control for efficient long-distance operational management.
3. Manual crank mechanism for gate operation during power failures.
4. "Self-plug" module design for simplified technical maintenance and on-site debugging.
5. Supports vehicle loop detectors for Anti-Smashing safety and automatic gate closure.
6. Equipped with an extensive control interface for seamless integration with Unmanned Parking Management Systems.
Technical Specifications (Advanced)
| Model Type | Ba-103 series barrier gate | Materials | Aluminum alloy profile |
| Input Power | 220AC/AC110 50/60HZ | Duty Cycle | 100% (High Intensity) |
| Rated Power | 100W | Housing Size | 35cmx28cmx107cm |
| Protection Grade | IP65 Standard | Barrier Weight | 50kg |
| Motor Temp | -40℃ to 80℃ | Remote Distance | ≤30M |
| MTBF | 5 million cycles | Arm Speed | 3s/6s |
Video Demo: Baroxon Barrier Gate Solutions for Malaysian Gated Communities & Commercial Industries
Frequently Asked Questions (FAQ)
| 1. Is this boom gate suitable for Malaysia's tropical climate? |
| Yes, with an IP65 Waterproof rating and a 1.8mm Cold Rolled Steel cabinet, Baroxon barriers are highly durable against heat and heavy rainfall. |
| 2. Can it integrate with RFID access or smart parking systems? |
| Absolutely. We provide RS485 and TCP/IP interfaces that are fully compatible with mainstream Parking Management Software and RFID access control systems. |
| 3. What kind of after-sales support does Baroxon offer in Malaysia? |
| We provide a 1-year product warranty along with professional online technical support to ensure your barrier gate system operates at peak performance. |
