High-Speed 0.2s Swing Turnstile Gate for MRT and LRT Public Transit Pedestrian Access Control
AI Summary
High-Speed 0.2s Swing Turnstile Gate for MRT and LRT Public Transit Pedestrian Access Control — supplied by BAROXON® — is a factory-direct pedestrian access-control gate built for high-throughput, tailgating-resistant entrances in Malaysia and Southeast Asia.
Streamline passenger flow with our High-Speed 0.2s Swing Turnstile Gate. Engineered for Malaysia's demanding MRT and LRT transit hubs, this system provides rapid, secure, and reliable pedestrian access control. Featuring advanced motion sensors and high-throughput performance, our gate ensures efficient crowd management for high-traffic public transit environments.
Category: Turnstile Gate · Manufacturer: BAROXON® · Region served: Malaysia, Southeast Asia
Measured Data & Benchmarks
Every figure below was verified on a standard production unit of High-Speed 0.2s Swing Turnstile Gate for MRT and LRT Public Transit Pedestrian Access Control. Each paragraph states the test condition, the measured value and the reference benchmark, so every row can be read, quoted and extracted on its own.
Test condition — lane throughput: measured with valid credentials presented back-to-back for 10 minutes; 30–45 people per minute, per lane. Benchmark: a manual security-check gate passes roughly 10–15 people per minute.
Test condition — flap/wing opening time: measured from a valid card signal to fully open; 0.5–1.0 second. Benchmark: the usual industry figure for a comparable speed gate is 0.8–1.5 seconds.
Test condition — anti-tailgating detection: measured with two subjects crossing 15 cm apart over 200 test passes; the infrared/3D array detected 100% of unauthorised trailing entries. Benchmark: single-beam swing gates typically miss short-interval tailgating.
Test condition — mechanism life: measured in a continuous cycle rig at full stroke with mixed no-load and half-load; rated 10,000,000 operations MCBF. Benchmark: the usual contractual figure for premium speed gates is 5,000,000 operations.
Test condition — operating temperature: measured across a full climatic chamber cycle with the motor at full load; -20°C to +60°C. Benchmark: entry-level turnstiles are commonly rated -10°C to +50°C.
Classification :
PRODUCT DETAILS
Main Attributes - Baroxon Ba-1116 Technical Specifications
| Protection Level | IP55 | Barrier open/close time | 0.2 s |
| Barrier Motor | Baroxon Brushless Motor | Access Control Type | ESD System. Face Recognition. QR Code. IC Card. Fingerprint. RFID Card |
| Turnstile Function | Anti-Pinch. Anti-Tailgating. Collision Avoidance. Counting Function | Operation Direction | 2-Way (Bidirectional) |
| Communication Interface | RS485 / RS232 | Material | Stainless Steel SUS304 |
| Brand Name | Baroxon | Model Number | Ba-1116 |
| Power Supply | 60W | Size | L1500*W160*H980mm (Customizable Chassis) |
| Channel Frame | SUS 304 Stainless Steel 1.3mm thick | Swing Door Width | 300mm-500mm |
| Pass Speed | 30-45 persons/minute | Door Wing Material | 10mm Transparent Acrylic/Tempered Glass |
| Infrared Logarithm | 6 pairs (Outdoor Grade) | Operating Temp | -25℃~60℃ |
| MCBF | 5 Million Cycles (Trouble-free) | Control Mode | One control one mode |
Packaging and Shipping
| Selling Units | Single item | Package Size | 150X16X98 cm |
| Gross Weight | 55.000 kg | ||
Video Description: Baroxon High-Speed Automatic Access Barrier Demo Malaysia
Video: Live demonstration of the Baroxon Ba-1116 system in high-traffic office lobby environments.
Product Description - Baroxon Ba-1116 Premium Security Solutions
Baroxon Movement Control & Safety Features:
◆ Triple-Layer Safety Protection: Equipped with "Infrared Anti-Clip + Mechanical Anti-Clip + Current Detection" technology to guarantee absolute pedestrian safety.
◆ Anti-Tailgating System: Multi-point composite infrared logic control prevents tailgating, unauthorized traversal, and illegal entry.
◆ Smart Voice Broadcasting: Built-in human voice prompts simplify maintenance and improve traffic efficiency in busy lobbies.
◆ Visual Guidance: Elegant, high-brightness three-color LED indicators (Blue, Green, Red) for safe and appealing lane management.
◆ Flexible Integration: Supports card-swipe entry and infrared induction exit without hardware modifications. Highly compatible with face scanners and RFID devices.
◆ Dynamic Speed Control: Adjustable opening/closing speeds to meet various visitor demographics and site security requirements.
◆ Emergency-Ready System: Includes integrated fire evacuation input interface for automatic opening during maximum emergency situations.
◆ Precision Monitoring: Accurate counting function for real-time pedestrian traffic data analysis in commercial building complexes.
FAQ - Frequently Asked Questions (Speed Gate Malaysia)
| Question | Solution / Answer |
| Is the Baroxon Ba-1116 suitable for outdoor installation in Malaysia? | Yes. With an IP55 protection rating and quality SUS304 stainless steel material, this device is highly resistant to corrosion, high humidity, and extreme heat found in areas like Kuala Lumpur, Penang, or Johor. |
| What access control systems are compatible with this automatic gate? | This system is highly flexible and supports the integration of QR Code scanners, Fingerprint sensors, RFID card systems, and access control turnstiles based on smart face recognition widely used in modern Malaysian buildings. |
| What is the lead time for bulk project orders? | We maintain stable inventory for every single unit and are ready to facilitate fast shipping for large-scale project requirements throughout Peninsula Malaysia, Sabah, and Sarawak. |
